Machined Socket Connectors 2.0 mm Straight Type
Home > Products > Connectors > Machined Socket Connectors 2.0 mm Straight Type

Machined Socket Connectors 2.0 mm Straight Type


  • Machined Socket Connectors 2.0 mm Straight Type

Machined Socket Connectors 2.0 mm Straight Type

    Payment Type: T/T,Paypal,Western Union
    Terms of Trade: FOB,CIF,EXW,FCA
    Min. Order: 1000 Bag/Bags
    Delivery Time: 10 Days
    Packaging: bag packing,Tube packing, reel packing
    Productivity: 100000K/month
    Brand: ANTENK
    Transportation: Ocean,Air
    Place of Origin: China
    Supply Ability: 100000K/month
    Certificate: ISO9001
    HS Code: 8536909000
    Port: SHENZHEN,SHENZHEN

Basic Info

Model No.: MFHDS-XXXXX01

Product Description

Shenzhen Antenk Electronics Co., Ltd. launched a Machined Socket Connectors 2.0 mm: MFHDS series electronic products

Founded in 2004, Shenzhen Antenk Electronics Co., Ltd. is located in Bao'an District, Shenzhen, Guangdong Province, one of China's most economically developed companies. The company's products mainly include board-to-board connectors, board-to-board connectors, wire-to-board connectors, and wire pairs. Wire connectors, I/O connectors, terminal blocks, network sockets, and various terminal internal lines and computer peripheral lines, etc., the products produced are in line with EU ROHS and REACH environmental requirements, most of the products have passed the US UL certification. , UL number E472792, the factory has passed ISO9001 and ISO14001 management system certification.

SPECIFICATIONS:
Insulator: PPS
Fiammability: UL 94V-0
Sleeve: Brass
Contact clip(3 finger): Beryllium copper
Mating pin ∅: 0.38 to 0.50 mm
Forces: (polished steel gauge ∅0.41mm)
-Insertion 0.5 N typ.
-Withdrawal 0.2 N typ.
Mechanical life: min 500 cycles
Rated cument: 1A
Contact resistance: max 10 mΩ
Dielectric strength: min 500V RMS

MFHDS-XXXXX01Machined Socket connectors 2.0 mm MFHDS series




ANTENK Electronics Co., Ltd(with the trade mark of "Antenk") was established in 2004. We specialize in producing precise Board to Board, Wire to Board Connector, Modular Jack, Terminal Block, Wire Harnesses,Cable Assemblies, I/O Connector. Through 15 years of development, we have grown into a leading manufacturer in Asia. We have passed ISO9001:2008 and ISO1400 Certification as well. Mostly of our products have been approved by UL, SGS and RoHS. Since its foundation, ANTENK sticks to the principle of specialization and tries its best to supply customers with products of high quality at competitive prices, by the precision high-speed punch molding, precise plastic injection molding and automatic assembly with the support of a skilled R&D and management team. The factory, with 3000M² floor plant, has about 100 employees and owns 15 sets precision molding devices, 4 sets Japan & Taiwan precision high-speed punch machines, more than 300 sets Various types of plastic molds and more than 100 sets hardware terminal molds, 10 sets laboratory testing equipments and over 50 sets machines for automatic assembly that can provide customer with over 10 types and 10,000 different specification Connectors parts, company have import-export handles rights. And up to 70% products are exported to Euro-American countries. Mainly customers: Foxconn, Flextronics, Molex, Amphenol, FCI, Siemens etc. famous companies.
